VVG41.20 - Siemens 2-port seat valve, external thread, PN16, DN20, kvs 6.3
£257.99
£214.99
On request
SKU
VVG41.20
Next Supplier Stock Update: 15/03/2025
EXPLORE MORE VERSIONS AND ACCESSORIES
Manuals & Datasheets
| DATA-SHEET |
 |
| Product type | Water Valve |
| Manufacturer | Siemens |
| Valve type | Globe Valve |
| Valve connection | External thread |
| Pressure | PN 16 |
| DN (mm) | DN 20 |
| Temperature range | -20°C to +120°C |
| Flow rate - m³/h | 6.3 kvs |
Find all the components for your ventilation system at IACS. All Siemens Valves in stock are ready for delivery in 5 to 7 days.
The Siemens VVG41.20 is a Valve used in HVAC Systems and Building control applications.
This Seat Valve provides a Pressure Nominal of PN 16.
The VVG41.20 Siemens Valve has a Diameter Nominal of DN 20.
The Amount of flow that this Ball Valve manages is KWS 6.3.
Find the best-priced Siemens Seat Valve that is compatible with your system at IACS.
If you have questions about size or installation, consult the Siemens custom datasheet above or send an email to iacs to get personalised guidance.
VVG Valves
∂ Bronze CuSn5Zn5Pb2 valve body
∂ DN 15...DN 50
∂ kvs 0.63...40 m3
/h
∂ Flat sealing connections with external thread G..B to ISO 228-1
∂ Sets of ALG…2 screwed fittings with threaded connection available from Siemens
∂ Can be equipped with SAX.. electromotoric or SKD.. and SKB.. electrohydraulic
actuators
