GSD361.1A - Siemens AC 230V, DC 0-10V, 2 N/m rotary damper actuator, 30s opening.

All of the Siemens Actuators that are in stock at IACS are delivered within 5 to 7 working days.

The Siemens GSD361.1A is an Actuator used in air ventilation and HVAC applications to open and close dampers.

The Torque force applied by the GSD361.1A is 2 Nm.

The Power Supply requested for this damper Actuator is 230Vac.

You may find the ideal Siemens Actuator for your system at IACS for a reasonable price.

If you have questions concerning size or installation, refer to the Siemens custom datasheet above or email IACS for individualised support.

GSD Actuators

Non-spring return rotary actuators. Application in ventilation and air conditioning plants to operate air dampers and air throttles.

● For damper areas up to 0.3 m2 , friction dependent.

● Suitable for use with modulating controllers (DC 0/2...10 V), open-close or three-position controllers.

● For directly driven zone dampers to control air flow in air ducts.

● We recommend a minimum pulse length of 500 ms on rotary actuators operated with

3-point control to ensure continuous and accurate operation.
