GS-CO-S - Sontay Space CO & Temperature transmitter 0-500ppm

£249.16 £207.63 Price match guarantee
On request
SKU
GS-CO-S
Next Supplier Stock Update: 16/03/2025
Manuals & Datasheets
 DATA-SHEET
DATASHEET

Product typeSensors & Stats
IP ratingIP30
Output Signal0..10Vdc, 4..20 mA
ManufacturerSontay
Sensor TypeAir Quality
Sensor characteristicsWall Mounted

Description

The Sontay CO range combines CO and Temperature in one housing. Using latest electro-chemical sensor technology with high repeatability and sensitivity to Carbon Monoxide gases in the ambient air, this sensor
ensures accurate and maintenance free operation in residential and commercial environments. The sensor modules have a catalytic ability to
ensure years of operation with no chance of sensor life degradation as known from other electro-chemical sensors.
A valuable feature of this sensor is it automatically detects the controller input type, Vdc or mA, when set to 3-wire mode.
IMPORTANT! The sensor is not designed, manufactured or intended to use or re-sale as control or monitoring equipment in environments
requiring life safety performance, in which the failure of the sensor could lead directly to death, personal injury or severe physical or

Features

  • Latest electro-chemical sensor technology with a lifetime up to
    10 years
  • Easy installation with LED indication, test button and autooutput mode detection (3-wire)
  • Supports 2-wire loop powering or 3-wire installation
  • Pluggable terminal blocks and tool free installation
  • Optional set point, fan speed & momentary switch



Output signals:
0-10Vdcor 4-20mA
Power supply:
24Vac/dc ±10% (3-wire)
24Vdc ±10% (2-wire)
Environmental: Operational:
Temp -10 to + 60°C
RH 5 to 95% non-condensing
Housing:
Material ABS
Colour RAL 9003 polished white finish
Dimensions 115 x 85 x 30mm
Protection:
IP30
