GQD126.1A - Siemens AC 24/DC 24V, 2-position, 2 N/m spring return rotary damper actuator with 2 auxillary switches, 30s opening, 15s closing on the spring.
£115.19
£95.99
On request
SKU
GQD126.1A
Next Supplier Stock Update: 16/03/2025
EXPLORE MORE VERSIONS AND ACCESSORIES
Manuals & Datasheets
| DATA-SHEET |
 |
| Product type | Actuator |
| IP rating | IP40 |
| Manufacturer | Siemens |
| Power Supply | 24Vac/Vdc |
| Torque | 2 Nm |
| Actuator type | Rotary |
| size | 73 x 122 x 63 mm |
The delivery time for all of the Siemens Actuators on hand at IACS is 5 to 7 working days.
The Siemens GQD126.1A is an Actuator used in air ventilation and HVAC applications to open and close dampers.
The Torque used by the GQD126.1A is 2 Nm.
This Siemens Actuator requests a Power Supply of 24Vac/Vdc.
IACS has the most affordable Siemens Actuator that works with your system.
Consult the Siemens custom datasheet above or contact IACS via email for personalised assistance if you have queries about size or installation.
GQD Actuators
• Electric motor-driven actuators for two-position and three-position control as well as DC 0…10 V control • 2 Nm nominal torque • AC/DC 24 V or AC 230 V rated voltage • Prewired with 0.9 m connecting cable • Spring return • Auxiliary switch for auxiliary functions
