GQD121.1A - Siemens AC 24/DC 24V, 2-position, 2 N/m spring return rotary damper actuator, 30s opening, 15s closing on the spring.
£98.39
£81.99
On request
SKU
GQD121.1A
Next Supplier Stock Update: 16/03/2025
EXPLORE MORE VERSIONS AND ACCESSORIES
Manuals & Datasheets
| DATA-SHEET |
 |
| Product type | Actuator |
| IP rating | IP40 |
| Manufacturer | Siemens |
| Power Supply | 24Vac/Vdc |
| Torque | 2 Nm |
| Actuator type | Rotary |
| size | 73 x 122 x 63 mm |
Deliveries take between 5 and 7 working days for all of the Siemens Actuators that IACS has on hand.
The Siemens GQD121.1A is an Actuator utilised in HVAC and air ventilation applications to handle dampers.
The force applied by the Torque of the GQD121.1A is 2 Nm.
This damper Actuator needs to be supported by a Power Supply of 24Vac/Vdc.
IACS offers the most economical Siemens Actuators for your system.
Refer to the Siemens custom datasheet above or email IACS for tailored support if you have any issues about size or installation.
GQD Actuators
• Electric motor-driven actuators for two-position and three-position control as well as DC 0…10 V control • 2 Nm nominal torque • AC/DC 24 V or AC 230 V rated voltage • Prewired with 0.9 m connecting cable • Spring return • Auxiliary switch for auxiliary functions
