CQK24A-SR SuperCap Zones Rotary Actuator, AC/DC 24 V, 75 s - Belimo | ideal for zone valves
£119.28
£99.40
On request
SKU
CQK24A-SR
Next Supplier Stock Update: 16/03/2025
EXPLORE MORE VERSIONS AND ACCESSORIES
Manuals & Datasheets
| DATASHEET |
 |
| IP rating | IP40 |
| Manufacturer | Belimo |
| Power Supply | 24Vac/Vdc |
| Torque | 1 Nm |
| Running time | 65 to 80 sec |
| Actuator type | Rotary |
| Ideal for | zone valves |
Find all parts for your ventilation system at iacs, the Free Delivery and 1-2 Delivery is available for all the Belimo Actuators in stock
The Belimo CQK24A-SR is a type of Actuator used in HVAC and ventilation systems.
This kind of Actuator rotates the damper in order to control it.
The force applied by the Torque of the CQK24A-SR is 1 Nm.
This Rotary Actuator needs to be supported by a power supply of 24Vac/Vdc.
IACS has the best prices on the right Belimo Actuators for your system.
Consult the Belimo custom datasheet above or contact iacs via email for personalised assistance if you have queries about size or installation.
CQK24A-SR SuperCap Zones Rotary Actuator, AC/DC 24 V, 75 s
- Modulating
- Motor running time 75 s
- Emergency position running time 60 s
- Operating range DC 2...10 V
- IP 40
- Connection cable PVC 1 m
- Adjustable flow rate value
Mode of operation: The actuator moves the valve to the desired operating position at the same time as the integrated capacitors are loaded. Interrupting the supply voltage causes the valve to be moved to the emergency setting position (POP) by means of stored electrical energy , taking into account the bridging time (PF) of 1 s which was set ex-works.
Pre-charging time (start up): The capacitor actuators require a pre-charging time. This time is used for chargingthe capacitors up to a usable voltage level. This ensures that, in the event of an electricity interruption, the actuator can move at any time from its current position into the emergency setting position (POP). The duration of the pre-charging time depends mainly on how long the power was interrupted.
Delivery condition (capacitors): The actuator is completely discharged after delivery from the factory, which is why the actuator requires approximately 25 s pre-charging time before initial commissioning in order to bring the capacitors up to the required voltage level.
Simple direct mounting: Tool-free snap assembly. The actuator can be plugged on the valve by hand (Caution! Just vertical movements). Pins must match the holes on the flange. The mounting orientation in relation to the valve can be selected in 180° increments. (Possible two times)
Manual override: Click out the actuator and rotate the valve stem with the help of the actuator.
High functional reliability: The actuator is overload protected, requires no limit switches and automatically stops when the end stop is reached.
Adjustable angle of rotation: The angle of rotation of the actuator can be changed by clip in 2.5° increments. This is used to set the maximum flow rate of the valve.
kv setting: Adjustable kv-values (C2..Q- ..) / max-values (C2..QP (T) - ..) are given in the respective zone valve data sheets. 2-way valve: Remove end stop clip and place at desired position. 3-way valve: Remove end stop clip (change-over application).
Electrical data:
- Nominal voltage AC/DC 24 V
- Nominal voltage frequency 50/60 Hz
- Nominal voltage range AC 19.2...28.8 V / DC 21.6...28.8 V
- Power consumption in operation 2.5 W
- Power consumption in rest position 0.5 W
- Power consumption for wire sizing 5 VA
- Connection supply / control Cable 1 m, 3 x 0.34 mm²
- Parallel operation Yes (note the performance data)
Functional data:
- Torque motor Min. 1 Nm
- Positioning signal Y DC 0...10 V
- Positioning signal Y note Input impedance 100 kΩ
- Operating range Y DC 2...10 V
- Direction of rotation emergency setting position (POP) fix deenergised closed (end stop NC = 0%)
- Manual override With actuator (clicked out) adjustable
- Running time motor 75 s / 90°
- Running time emergency control position 60 s / 90°
- Sound power level motor 35 dB(A)
- Sound power level emergency control position 35 dB(A)
- Position indication Mechanical
- Flow setting see product features
Safety:
- Protection class IEC/EN III Safety extra-low voltage
- Degree of protection IEC/EN IP40
- EMC CE according to 2004/108/EC
- Certification IEC/EN IEC/EN 60730-1 and IEC/EN 60730-2-14
- Mode of operation Type 1.AA
- Rated impulse voltage supply / control 0.8 kV
- Control pollution degree 2
- Ambient temperature 5...40°C
- Non-operating temperature -7...50°C
- Ambient humidity 95% r.h., non-condensing
- Maintenance Maintenance-free
Weight approx.: 0.2 kg
Abbreviations POP = Power off position / emergency setting position, PF = Power fail delay time / bridging time
